Product Overview
Challenger 44018E Medium-Duty Extended 4-Post Lift 18,000 lb – New Black Color
The Challenger 44018E is a premium 18,000 lb. capacity medium-duty 4-post lift engineered for automotive service facilities that demand reliability, versatility, and exceptional build quality. Now available in the new Black Color with Challenger's upgraded textured paint formula, this extended-length model is designed specifically for shops servicing light and medium-duty vehicles including larger SUVs, vans, and medium-duty trucks. With its 24' 4" overall length, the 44018E provides the extra reach needed for today's longer wheelbase vehicles while maintaining the robust construction and advanced safety features Challenger is known for.
Built for demanding commercial environments, the Challenger 44018E features a superior lifting system utilizing high tensile strength leaf chain and sealed roller bearings for maximum reliability and productivity. The heavy-duty cylinder delivers optimum lifting performance with minimal maintenance requirements, while the offset flared post column design provides exceptional rigidity and stability during operation. This lift is engineered to handle the daily workload of busy shops performing maintenance, repairs, and inspections on a wide variety of vehicle types.
Extended Length Design for Maximum Versatility
The 44018E offers an impressive 24' 4" overall length with a 240" between-columns measurement and a maximum wheelbase capacity of 230". This extended configuration makes it ideal for servicing larger vehicles, extended cab trucks, cargo vans, and specialty vehicles that standard-length lifts simply cannot accommodate. Despite its extended reach, the lift maintains a manageable 11' 6-1/8" overall width, allowing it to fit into most standard bay configurations without sacrificing valuable shop floor space.
The 22" wide runways provide ample tire contact area for secure vehicle positioning, while the 36" / 54" adjustable runway spacing accommodates a variety of tread widths for different vehicle types. The diamond plate anti-skid runways and ramps ensure positive vehicle traction during drive-on and drive-off operations, enhancing both safety and operator confidence. The lift delivers an impressive 78-3/4" rise height, providing excellent undercarriage access for thorough inspections and repairs.
Complete Alignment Package Option Available
For shops offering wheel alignment services, the AR44018AR four-post alignment truck lift package transforms this capable service lift into a comprehensive alignment solution. The alignment package includes two 9,000 lb. capacity rolling jacks (RJ9000), stainless steel turning radius gauges, and an internal airline kit for dual rolling jack operation. This 18,000 lb. alignment rack is the perfect complement to any medium-duty automotive service operation requiring professional-grade alignment capabilities.
The alignment-ready configuration offers a 4-wheel alignment range from 98" to 206" and a maximum 2-wheel alignment capacity of 220". Combined with 17 level locking heights, this versatility makes the AR44018AR the right rack for precision wheel alignment work as well as general service operations on a wide variety of medium-duty vehicles.
Advanced Safety and Convenience Features
Safety and operator convenience are paramount in the 44018E design. The single point lock release system allows technicians to disengage all column locks simultaneously, streamlining the lowering process and improving workflow efficiency. This feature is especially valuable in high-volume shops where time efficiency directly impacts productivity and profitability.
The lift features a built-in runway rail system that provides exceptional convenience for optional rolling jacks and oil drain pans. This integrated rail system eliminates the need for floor-mounted tracks, keeping your shop floor clean and organized while providing smooth, guided movement of service accessories. The adjustable runways accommodate various tread widths for medium-sized transit vehicles, though fixed runways are required when utilizing rolling jack applications for optimal stability.
Optional accessories including ramp kits, oil drain pans, turning radius gauges, and rolling jacks make the 44018E a perfect supplement to any service facility working on light and medium-duty automobiles and trucks. These accessories transform the lift into a complete service solution tailored to your shop's specific needs.
Reliable Power and Performance
Powered by a robust 3HP motor operating on single-phase 208v-230v electrical power at 30 amps, the Challenger 44018E delivers consistent, reliable performance throughout your workday. The lift achieves a rapid 60-second speed of rise, minimizing vehicle lift time and maximizing technician productivity. For shops with three-phase power availability, optional three-phase electrical configurations are available upon request at time of order.
The 8' 6-1/2" overall height of the lift allows it to fit comfortably in facilities with standard ceiling heights, while the 7-1/4" runway height provides a low-profile entry that accommodates vehicles with lower ground clearance. With a shipping weight of 4,350 lbs., the 44018E is substantial enough to provide rock-solid stability while remaining manageable for installation and positioning.
Key Selling Points
- 18,000 lb. capacity with 24' 4" extended length for medium-duty vehicles and longer wheelbases
- High tensile strength leaf chain and sealed roller bearings for maximum reliability and minimal maintenance
- Single point lock release for simultaneous disengagement of all column locks, improving workflow efficiency
- Built-in runway rail system for convenient use of optional rolling jacks and accessories
- New Black Color with upgraded textured paint formula for enhanced durability and professional appearance
Watch the Challenger 44018E in action and see how its extended length, robust construction, and advanced features deliver the performance and reliability your shop demands.
Product Features
- Superior lifting system features high tensile strength leaf chain and sealed roller bearings for maximum reliability and productivity
- Heavy duty cylinder provides optimum lifting with minimum downtime and minimal maintenance
- Single point lock release allows techs to disengage all column locks simultaneously
- Diamond plate anti-skid runways and ramps for positive vehicle traction
- Adjustable runways to accommodate tread widths of a variety of medium sized transit vehicles (rolling jack application requires fixed runways)
- Built-in runway rail system provides convenience for optional rolling jacks & oil drain pan
Product Specifications
Model Number
44018
44018E
44018AR
Lift Capacity
18,000 lbs.
A Length Overall
21' 4"
24' 4"
25' 11-1/2"
B Width Overall
11' 6-1/8"
11' 9-1/2"
C Inside of Columns
121"
122"
D Between Columns
204"
240"
204"
E Height Overall
8' 6-1/2"
F Height of Runways
7-1/4"
11-7/8"
G Width of Runways
22"
H Width Between Runways
36" / 54"
I Maximum Wheelbase
194"
230"
236"
J Rise Height
78-3/4"
83-3/8"
Min.-Max. 4 Wheel Align
N/A
98" – 206"
Max. 2 Wheel Alignment
N/A
220"
Motor
3HP
Voltage (Single Phase)
208v – 230v
Speed of Rise
60 seconds
Amps
30
Shipping Weights
3930 lbs. (1783 kg)
4350 lbs. (1973 kg)
5050 lbs. (2290 kg)
- Optional Three Phase Electrical Power Available. Please Specify at time of order.
Available in Red and Blue only.
Key Features
- Published product configuration: Challenger 44018E Medium-Duty Extended 4-Post Lift 18,000 lb – New Black Color The Challenger 44018E is a premium 18,000 lb. capacity medium-duty 4-post lift engineered for automotive service facilities that demand reliability, versatility, and exceptional build quality. Now available in the new Black Color with
- Exact manufacturer model or part number: 44018E-V001
- Cataloged for Lifts & Hoists: Car Lifts — 4 Post Lifts – Heavy-Duty
- 2 product manual or technical documents linked below
- Condition: New
Product Specifications
| Brand | Challenger |
|---|---|
| SKU | 44018E-V001 |
| MPN / Model | 44018E-V001 |
| Condition | New |
| Division | Lifts & Hoists |
| Primary Category | Car Lifts |
| Collection | 4 Post Lifts – Heavy-Duty |
Before You Order
Confirm that model 44018E-V001, the listed capacity or working range, power requirements, dimensions, and site-delivery needs match your application. Only specifications stated in this listing should be used for purchase planning.
