Product Overview
BendPak P9000LT Low-Rise, Open-Center Pit-Style ALI Lift 9,000 lb.
The Undisputed World's Best Pit Lift
9,000 lbs. of lifting capacity. Unobstructed access to the vehicle's undercarriage. Optional ramps or flush-mount design. Minimal footprint. Optional arm adapters. The BendPak P-9000LT is simply the best low-rise car lift money can buy. Fast-lube shops have relied on BendPak pit lifts for years, and our engineers took the proven design to the next level by significantly increasing weight capacity.
The P-9000LT is suitable for more light trucks and SUVs than ever before. Whether you choose the extended approach ramps or flush-mount option, lifting low-stance vehicles is effortless with this lift. It's engineered for maximum versatility, allowing you to convert fast-lube pits into full-service wheel service work bays without sacrificing valuable floor space or center pit access.
Surface and Flush-Mount Options: Ultimate Installation Flexibility
Whether you work in a pit or prefer to keep your low-rise lift on the ground, the BendPak P-9000LT is versatile enough to do both. Converting the flush-mount P-9000LTF into a floor model is as simple as attaching the extended approach ramps. These heavy-duty ramps are extended farther and slope very gradually, ensuring low ground-clearance vehicles never scrape or rub against them during drive-up.
The P-9000LT is made with oil-change facilities first and foremost in mind. The open-center, frame-engaging design permits full access to the wheels for tire and brake service, transforming your oil-change business into a legitimate threat to competing auto shops who used to monopolize your wheel service business. Those profitable tire rotations, brake jobs, and suspension services are now within your reach. Capture all that revenue in-house with a lift designed to deliver full-service capability in a compact, pit-friendly package.
This industry-leading lift features a robust 1.5 HP electric-hydraulic power unit, dual hydraulic cylinders with precision flow-divider, simple electronic push-button controls, and automatic multi-position pneumatic safety locks with air release for safe, remote operation.
Key Features & Design Advantages
Pneumatic Lock Release
Air locks provide a safe, instant release that efficiently permits the lowering of vehicles. A single button push is all it takes to disengage the locks and completely lower the lift in seconds flat. This automatic multi-position safety lock system ensures safe operation at any of the lift's multiple locking heights: 15", 19", 21.5", 23.5", and full rise at 24".
Low-Profile Design
At just 4" high when fully lowered, the P-9000LT is one of the most space-effective pit lift models ever engineered. When flush-mounted, its profile virtually disappears completely, leaving your work area clear and unobstructed. The lift platform itself measures 58.5" long by 24" wide, providing ample support while maintaining a compact footprint.
Rugged Steel Channel Frame
The super-wide base provides this 9,000 lbs. of lifting force with excellent support and stability. No one matches the reinforced steel channel frame design of the P-9000LT. Reinforced parallel lifting arms and a reinforced upper lift platform better support inboard loading for maximum safety and performance. BendPak pioneered this design, and ongoing heavy-duty construction ensures we remain the industry leader.
Dual-Pump Power Unit with Built-In Proportioning Valve
The dual-pump hydraulic system ensures smooth, balanced lifting every time. Integrated proportioning valve guarantees even pressure distribution across both cylinders for perfectly level vehicle positioning. Combined with the 1.5 HP / 208-230 VAC / 60 Hz / 1 Ph motor, this lift achieves full rise in just 55 seconds, making your workflow faster and more productive.
Solid Rubber Lift Blocks & Durable Rubber-Topped Pads
We don't charge extra for the rubber blocks you need to lift vehicles safely. These rugged blocks protect vehicle undercarriages and chassis from damage. They're made to take as much use and abuse as your work requires. The durable rubber-topped pad surface provides excellent grip and quick, secure set-up every time.
Enhanced Adjustable Lifting Arms (Optional)
For even greater vehicle compatibility, optional adjustable lifting arms are available, allowing you to fine-tune lift point positioning to match a wider variety of vehicle configurations and lift points.
Detailed Instructions & Professional Support
Every BendPak lift comes complete with an easy-to-read instruction manual, space to keep service records, a comprehensive guide for safe lifting, and a safety/training instruction placard. BendPak stands behind every lift with thorough documentation and support to ensure safe, efficient operation for years to come.
Choose Flush-Mount for Maximum Clearance
The P-9000LTF flush-mount pit lift mounts flush against the concrete for a completely recessed drive-over option. If you don't want to see the car lift, or you simply need it out of the way in your busy garage, the ramps are completely detachable. That means if you change your mind, you can easily convert your P-9000LT into a P-9000LTF at any time. The Model P-9000LTF gives you the ultimate in installation flexibility and space efficiency.
Why Choose the BendPak P-9000LT?
- 9,000-lb. lifting capacity handles light trucks, SUVs, and a wide range of passenger vehicles
- Reinforced construction with parallel lifting arms and upper lift platform for superior inboard loading support
- Easily converts fast-lube pits into wheel service work bays capture more revenue in-house
- Mounts outside the pit rail without interfering with center work area – maximum access and workspace flexibility
- Electronic push-button controls allow smooth, single-hand operation for effortless lifting and lowering
Product Features
- 9,000-lb. lifting capacity
- Reinforced parallel lifting arms to better support inboard loading
- Reinforced upper lift platform to better support inboard loading
- Dual-pump power unit with built in proportioning valve
- Easily convert fast-lube pits into wheel service work bays
- Mounts outside the pit rail without interfering with center work area
- Model P-9000LTF flush-mount provides recessed drive-over option
- Heavy duty 1.5 HP electric-hydraulic power unit
- Electronic push-button controls allow smooth, single-hand operation
- Automatic multi-position safety locks with air release deliver safe, remote operation
- Powder-coat finish
- Durable rubber-topped pad surface and rubber lift blocks provide quick set-up
- Enhanced adjustable (optional) lifting arms
Product Specifications
Model
P-9000LT
P-9000LTF
Style
Low-Rise
Low-Rise Flush Mount
Capacity
Lifting Capacity:
9,000 lbs. (4,082 kg)
Rise
Max Lifting Height
24” (610 mm)
Max Lift Height + Blocks
27” (686 mm)
Time to Full Rise
55 seconds
Outside Dimensions
Overall Length
124.6” (3,165 mm)
74.4” (1,890 mm)
Overall Lift Platform Length
58.5” (1,484 mm)
Overall Lift Platform Width
24” (610 mm)
Lowered Height
4” (102 mm)
4" (102 mm)
Locking Heights
Fully Lowered
4" (102 mm)
1st Lock
15" (381 mm)
2nd Lock
19" (483 mm)
3rd Lock
21.5" (546 mm)
4th Lock
23.5" (597 mm)
Full Rise
24" (610 mm)
Power Unit
Motor
1.5 HP / 208-230 VAC / 60 Hz / 1 Ph
Shipping
Weight
1,502-lbs. (681 kg)
1,134-lbs. (514 kg)
Dimensions
77" x 40" x 24"
(1,943 mm x 1,016 mm x 609 mm)
77" x 60" x 24"
(1,943 mm x 1,534 mm x 609 mm)
Key Features
- Published product configuration: BendPak P9000LT Low-Rise, Open-Center Pit-Style ALI Lift 9,000 lb. The Undisputed World's Best Pit Lift 9,000 lbs. of lifting capacity. Unobstructed access to the vehicle's undercarriage. Optional ramps or flush-mount design. Minimal footprint. Optional arm adapters. The BendPak P-9000LT is simply the best low-rise car
- Exact manufacturer model or part number: 5175133
- Cataloged for Lifts & Hoists: Car Lifts — Specialty Lifts
- 4 product manual or technical documents linked below
- Condition: New
Product Specifications
| Brand | BendPak |
|---|---|
| SKU | 5175133 |
| MPN / Model | 5175133 |
| Condition | New |
| Division | Lifts & Hoists |
| Primary Category | Car Lifts |
| Collection | Specialty Lifts |
Before You Order
Confirm that model 5175133, the listed capacity or working range, power requirements, dimensions, and site-delivery needs match your application. Only specifications stated in this listing should be used for purchase planning.
Manuals & Technical Resources
Need more technical details or compatibility information? Contact our team and we will help you find the right fit.
