Product Overview
BendPak HD-7500BLX Vehicle & Boat Storage Lift w/82" Rise
Never trust your precious boat to the unpredictability of the water, nor should you continue paying for expensive dry docks and yard storage. The BendPak HD-7500BLX is engineered to safeguard your investment by keeping your boat high, dry, and protected from the elements. With a robust 7,500-lb lifting capacity and an impressive 82-inch rise, this professional-grade storage lift provides reliable protection from salt water corrosion, barnacles, rust damage, rub marks, rot, and cold weather damage. Best of all, its adjustable runway design means it pulls double-duty as a full-function vehicle lift—perfect for cars, trucks, and boats alike.
Why Choose the BendPak HD-7500BLX?
The HD-7500BLX is the perfect boat lift for dry docking and year-round storage. Salt water, tides, floods, and choppy conditions can wreak havoc on boats stored in-water or at docks. By storing your boat in your own garage or facility, you eliminate monthly storage fees and protect against costly water-related damage. This lift is crafted to the same strict engineering standards as BendPak's automotive lifts, ensuring exceptional safety, longevity, and peace of mind.
Business owners operating boat storage facilities will especially appreciate the HD-7500BLX. More storage space equals higher revenue, and offering customers the safest, most reliable boat storage solution available is one of the smartest investments you can make. This lift accommodates most boat trailers with wide and narrow installation configurations, making it a versatile choice for a variety of customers and craft.
Engineered for Strength and Reliability
BendPak designed and engineered the HD-7500BLX with the same commitment to quality that defines all of their automotive lifting equipment. This lift features a dependable electric-hydraulic power system with a single hydraulic cylinder mounted underneath the runway for minimal exposure and maximum durability. Four heavy-duty 3/8-inch aircraft-grade stainless steel wire ropes each rated to hold 14,400 lbs provide unmatched strength and peace of mind.
The lift is equipped with internal anti-sway slider blocks in each column to minimize movement, along with dual-hub wire rope sheaves that reduce stress on axles, sheaves, and cables. Over-sized, self-lubricating cable rollers and rugged 1-1/4-inch roller axles ensure smooth, consistent operation for years to come.
Safety is paramount. The HD-7500BLX includes multi-position safety locks in each column 17 locking positions spaced every 4 inches allowing for variable-height parking and ultimate flexibility. All four independent safety locks are released simultaneously with a convenient push-button pneumatic release. Spring-loaded locks engage automatically as the lift rises, and a secondary lock system acts as a slack-cable device for emergency protection.
Designed for Ease of Use
The HD-7500BLX was engineered for quick, hassle-free operation. Longer, low-profile approach ramps with a non-skid surface make it easy to load boat trailers onto the runways. Runways are 19 inches wide and 188.5 inches long, with adjustable width settings to accommodate boat trailers of various sizes. The lift's adjustable lock ladders and integrated design—with all lifting cables, airlines, safety latches, and sheaves fully enclosed—protect critical components and extend the lift's lifespan.
The entire unit is finished with a durable powder coat for superior corrosion resistance, ensuring it looks and performs like new even in demanding environments. Controls are conveniently located for easy access, and the lift reaches full rise in approximately 50 seconds.
Dual-Purpose Versatility
Because the HD-7500BLX features fully adjustable runways, it isn't limited to boat storage. Use it to store vehicles, trucks, or any wheeled equipment you need to keep off the ground. The lift supports a maximum lifting height of 87 inches, with a minimum runway height of just 5 inches, making it easy to drive on and off. The 108.5-inch drive-thru clearance provides ample room for loading and maneuvering.
Whether you're a homeowner looking to maximize garage space or a business owner seeking to expand your boat storage offerings, the HD-7500BLX delivers unbeatable versatility and value.
What's Included
The BendPak HD-7500BLX comes complete with the TC-3000 Telescoping Boat Trailer Tongue Platform, which provides an additional 3,000-lb capacity to safely support and stabilize boat trailer tongues during storage. This included accessory ensures your trailer is fully supported from front to back, protecting both the trailer and your boat from unnecessary stress.
Key Highlights
- 7,500-lb lifting capacity with 82-inch maximum rise
- 17 locking positions spaced every 4 inches for flexible storage heights
- Heavy-duty 3/8-inch aircraft cable and single hydraulic cylinder design for dependable, maintenance-free operation
- Adjustable runways accommodate boats, cars, trucks, and most trailer types
- Push-button pneumatic safety release with automatic spring-loaded locks and secondary emergency protection
Watch the BendPak HD-7500BLX in Action
Protect Your Investment
Remember, dry docking is the only way to ensure that boats are safe from water-related damage. With an in-water lift, choppy waters, floods, and tides can make an unexpected mess of your beautiful boat. Don't take chances! Keep your boat high, dry, and protected with the BendPak HD-7500BLX boat and vehicle storage lift—engineered for safety, built for performance, and designed to save you money while safeguarding your most valuable assets.
Product Features
- 7,500-pound lifting capacity
- Two different lifting heights to choose from
- Electric / hydraulic power system
- Internal anti-sway slider blocks in each column
- Both models feature heavy-duty 3/8" aircraft cable
- Multi-position safety locks in each column
- Ramps feature non-skid surface
- Two different ramp lengths to choose
- Single hydraulic cylinder underneath runway
- Over-sized self-lubricating cable rollers
- Rugged 1-1/4" roller axles
- Adjustable lock ladders
- Push-button pneumatic safety release
- Durable powder coat finish
Includes
TC-3000 Telescoping Boat Trailer Tongue Platform 3,000-lb. Capacity. For more info
Product Specifications
Model
HD-7500BLX
HD-75BXT
HD-7500PBX
Capacity
Lifting Capacity: (*)
7,500 lbs. / 3,175 kg
Max capacity / Front Axle:
3,750 lbs. / 1,701 kg
Max capacity / Rear Axle:
3,750 lbs. / 1,701 kg
Rise
A Min. Runway Height
5" (125 mm)
B Max. Rise
82" / 2,083 mm
144.5" / 3681 mm
C Max. Lifting Height
87" / 2,210 mm
132" / 3357 mm
Time to Full Rise
≈50 seconds
N/A
Outside Dimensions
D Overall Width
132.5" (3,358 mm) (with fasteners 133.75" / 3,398 mm)
E Outside Length
198" / 5,028 mm
222" / 5,639 mm
198" / 5,028 mm
F Overall Length
224.5" / 5,704 mm
248.5" / 6,312 mm
224.5" / 5,704 mm
G Height of Columns
100" / 2,540 mm
157.5" / 4,010 mm
Inside Dimensions
H Width Between Columns
122" / 3,103 mm
I Drive-Thru Clearance
108.5" / 2,756 mm
Runway
J Runway Width
19" / 483 mm
K Length of Runways
188.5" /4,788 mm
212.5" / 5,398 mm
188.5" /4,788 mm
L Width Between Runways
49.5" – 69.5" / 1,257 – 1,689 mm
46.5" – 66.5" / 1,181 – 1,689 mm
49.5" – 69.5" / 1,257 – 1,689 mm
M Runway Centerline
68.5" narrow or 88.5" wide (1,740 or 2,248 mm)
N/A
N Outside Edge of Runways
87.5" narrow or 107.5" wide (2,223 or 2,731 mm)
Drive-Thru Clearance
108.5 " / 2,756 mm
Minimum Wheelbase
Rated Capacity
135" / 3,429 mm
150" / 3,810 mm
N/A
75% Capacity
115" / 2,921 mm
130" / 3,302 mm
N/A
50% Capacity
95" / 2,413 mm
110" / 2,794 mm
N/A
25% Capacity
80" / 2,032 mm
90" / 2,286 mm
N/A
Locking
Locking Positions
17
30
Lock Spacing
Every 4" (102 mm)
Power Unit
Motor
208-230 VAC, 60 Hz, 1 Ph
Air Supply
3 to 25 cfm @ 50 to 150 psi
Note: An air supply (minimum: 30 psi / 3 CFM) is required for the safety-lock mechanisms to disengage. It is solely the responsibility of the end-user to provide, install and maintain the air supply.
Key Features
- Published product configuration: BendPak HD-7500BLX Vehicle & Boat Storage Lift w/82" Rise Never trust your precious boat to the unpredictability of the water, nor should you continue paying for expensive dry docks and yard storage. The BendPak HD-7500BLX is engineered to safeguard your investment by keeping your boat high, dry, and protected from the
- Exact manufacturer model or part number: 5175315-V001
- Cataloged for Lifts & Hoists: Car Lifts — Parking Lifts
- 4 product manual or technical documents linked below
- Condition: New
Product Specifications
| Brand | BendPak |
|---|---|
| SKU | 5175315-V001 |
| MPN / Model | 5175315-V001 |
| Condition | New |
| Division | Lifts & Hoists |
| Primary Category | Car Lifts |
| Collection | Parking Lifts |
Before You Order
Confirm that model 5175315-V001, the listed capacity or working range, power requirements, dimensions, and site-delivery needs match your application. Only specifications stated in this listing should be used for purchase planning.
Manuals & Technical Resources
Need more technical details or compatibility information? Contact our team and we will help you find the right fit.
