Product Overview
Weka DK52 Core Drill is a core drill designed for rig-mounted or handheld penetrations for plumbing, electrical, HVAC, and anchoring. The DK52 configuration pairs Electric power source, 4000 W output power, and 13 lb weight.
Key Features
- 230V power/drive requirement captured for jobsite planning
- <=24" drilling or boring capacity for selecting the right bit and setup
- 440 RPM speed range or gearbox detail supports bit-size control
- 1.250"-7 spindle/thread detail helps confirm bit and adapter compatibility
- Rig-Mounted mount/system configuration supports correct rig pairing
- Rig-mounted format supports controlled feed and larger diameter core work
Product Specifications
- Tool Mount
- Rig-Mounted
- Available Variants
- DK52 230 V 3PH; DK52 460 V 3PH
- Model #
- DK52
- SKU/Part #
- 4244061
- Product Type
- Core Drill
- Product Subtype
- Drill Motor
- Product Mount
- Rig-Mounted
- Engine/Motor
- Electric Motor
- Horse Power
- Heavy Duty
- Power Source
- Electric
- Voltage
- 230V
- Amperage
- 18 AMP
- Power Phase
- 1PH
- Variable Speed
- 3-Speed
- Speed 1 Max RPM
- 150 RPM
- Speed 2 Max RPM
- 290 RPM
- Speed 3 Max RPM
- 440 RPM
- Max Speed RPM
- 440 RPM
- Recommended Bit Diameter
- 3" – 20"
- Max Bit Diameter
- <=24"
- Drilling Depth per Pass
- User-Dependent
- Spindle Features
- 1.250"-7
- Dust Collection System
- Not applicable
- Weight (lbs)
- 13 lb
- Shipping Weight
- 59.1
- Clutch
- Slip
- Compact Design
- Yes
- Applications
- Concrete, Masonry, Stone
- Dry/Wet
- Wet
- Power Compatibility
- Standard Electric Supply
- Product Warranty
- 1 Year
- WooCommerce SKU
- 48023
- Store Title
- WEKA DK52 Core Drill Motor
- Manufacturer Part Number
- 4244061 for listed 230 V variant
- Nominal Power
- 5200 W
- Output Power
- 4000 W
- Manufacturer Drilling Diameter
- 110 – 500 mm
- Manufacturer Weight
- 22.9 kg without cable
- Included
- Core drill motor in listed voltage/phase configuration; stand, core bit, vacuum pump, and water tank sold separately unless stated
Applications & Purchase Considerations
The DK52 is best matched to rig-mounted or handheld penetrations for plumbing, electrical, HVAC, and anchoring where the job requires Electric power source, 4000 W output power, and 13 lb weight.
- Site utility or fuel: 230V
- Tooling or working setup: Core drill motor in listed voltage/phase configuration; stand, core bit, vacuum pump, and water tank sold separately unless stated
- Handling reference: 13 lb
- Confirm delivery ZIP code and carrier-accessible receiving details before checkout
Product Identification
| Brand | Weka |
|---|---|
| SKU | 48023 |
| MPN / Model | 48023 |
| Condition | New |
| Division | Concrete Equipment |
| Primary Category | Core Drilling |
| Collection | Core Drill Motors |
| Product Type | Core Drill |
Before You Order
Confirm that model 48023, the listed capacity or working range, power requirements, dimensions, and site-delivery needs match your application. Only specifications stated in this listing should be used for purchase planning.
Need more technical details or compatibility information? Contact our team and we will help you find the right fit.
