Product Overview
Husqvarna DM 540i Core Drill is a core drill designed for rig-mounted or handheld penetrations for plumbing, electrical, HVAC, and anchoring. The DM 540i configuration pairs Battery power source, 1.88 hp per manufacturer battery product listing output power, and 10.8 lbs weight.
Key Features
- BLi-X power/drive requirement captured for jobsite planning
- 4" drilling or boring capacity for selecting the right bit and setup
- 1,400 rpm speed range or gearbox detail supports bit-size control
- 1 1/4" 7 UNC spindle/thread detail helps confirm bit and adapter compatibility
- Hand-Held mount/system configuration supports correct rig pairing
- Hand-held format supports fast setup for smaller penetrations and repair work
Product Specifications
- Max Bit Diameter
- 4"
- Power Source
- Battery
- Recommended Bit Diameter
- 0.59" – 4"
- Tool Mount
- Hand-Held
- Wet/Dry Use
- Wet/Dry
- Illustrated part list
- Illustrated part list IPL. DM 540i. 2021-09 PDF ANY
- Available Variants
- Bare tool; kit with 2 x BLi300 batteries and QC500 charger
- Battery eco system
- BLi-X
- Drill bit diameter handheld, max
- 3 in
- Drill bit diameter with stand, max
- 4 in
- Recommended drill bit diameter, min
- 0.59 in
- Coolant
- Wet /dry
- Number of gearbox speeds
- 2
- Numbers of electronical gearbox speeds
- 2
- Spindle speed unloaded gear 1
- 1,400 rpm
- Spindle speed unloaded gear 2
- 4,450 rpm
- Water connector
- Gardena Male
- Water pressure, max
- 43.5 psi
- Mounting collar
- 2.36 in
- Spindle thread, inner
- G 1/2"
- Spindle thread, outer
- 1 1/4" 7 UNC
- Product size length
- 17.32 in
- Product size width
- 4.33 in
- Product size height
- 10.83 in
- Weight
- 10.8 lbs
- Packaging length (Calc)
- 23.622 in
- Packaging width (Calc)
- 8.661 in
- Packaging height (Calc)
- 15.748 in
- Article gross weight (Calc)
- 27.117 lbs
- Sound power level, guaranteed (LWA)
- 97 dB(A)
- Sound power level, measured
- 86 dB(A)
- Sound pressure level at operators ear
- 86 dB(A)
- Warranty
- 2 year limited
- WooCommerce SKU
- 970493706
- Store Title
- Husqvarna DM 540i
- Output Power
- 1.88 hp per manufacturer battery product listing
- Battery System
- BLi-X
- Included
- Core drill motor in listed voltage/phase configuration; stand, core bit, vacuum pump, and water tank sold separately unless stated
Applications & Purchase Considerations
The DM 540i is best matched to rig-mounted or handheld penetrations for plumbing, electrical, HVAC, and anchoring where the job requires Battery power source, 1.88 hp per manufacturer battery product listing output power, and 10.8 lbs weight.
- Site utility or fuel: Battery
- Tooling or working setup: Core drill motor in listed voltage/phase configuration; stand, core bit, vacuum pump, and water tank sold separately unless stated
- Handling reference: 10.8 lbs
- Confirm delivery ZIP code and carrier-accessible receiving details before checkout
Product Identification
| Brand | Husqvarna Construction |
|---|---|
| SKU | 970493706 |
| MPN / Model | 970493706 |
| Condition | New |
| Division | Concrete Equipment |
| Primary Category | Core Drilling |
| Collection | Core Drill Motors |
| Product Type | Core Drill |
Before You Order
Confirm that model 970493706, the listed capacity or working range, power requirements, dimensions, and site-delivery needs match your application. Only specifications stated in this listing should be used for purchase planning.
Need more technical details or compatibility information? Contact our team and we will help you find the right fit.
