Product Overview
Diamond Products CC1000 Concrete Joint Saw is a concrete joint saw designed for early-entry control joints in fresh concrete slabs. The CC1000 configuration pairs Electric power source, 8 in blade capacity, and Up Cut cut direction.
Key Features
- 8 in cutting capacity supports the intended blade or bar setup
- 3,800 rpm shaft or chain speed detail for matching tooling and application
- Built for early-entry control joints that help reduce random cracking
- Compact format supports fast work after finishing green concrete
- Useful for sidewalks, commercial slabs, driveways, and flatwork
- Electric power configuration for matching site conditions
Product Specifications
- Model
- CC1000
- Cut Direction
- Up Cut
- Power Source
- Electric
- Catalog Number
- 47104
- Part Number
- 5800552
- Blade capacity
- 8 in
- Max cutting depth
- 2-1/4 in
- Blade shaft rpm
- 3,800 rpm
- Blade shaft diameter
- 1 in
- Arbor diameter
- 1 in or optional 5/8 in
- Frame
- 1/8 in steel
Applications & Purchase Considerations
The CC1000 is best matched to early-entry control joints in fresh concrete slabs where the job requires Electric power source, 8 in blade capacity, and Up Cut cut direction.
- Site utility or fuel: Electric
- Tooling or working setup: 8 in
- Confirm delivery ZIP code and carrier-accessible receiving details before checkout
Product Identification
| Brand | Diamond Products |
|---|---|
| SKU | 47104 |
| MPN / Model | 47104 |
| Condition | New |
| Division | Concrete Equipment |
| Primary Category | Cutting |
| Collection | Early Entry Concrete Saws |
| Product Type | Concrete Joint Saw |
Compatibility & Ordering Notes
Use SKU / MPN 47104 as the primary ordering reference. Before purchase, match the equipment model, serial-number range, mounting or connection details, and any size or electrical requirements shown in the listing. Compatibility is not implied beyond the verified information above.
Need more technical details or compatibility information? Contact our team and we will help you find the right fit.
